EMM Micro connectors - 1.27mm pitch MIL-DTL-83513

EMM Micro connectors - 1.27mm pitch MIL-DTL-83513

With its 1.27mm pitch, it achieves more than 40% space reduction compared to its parent CMM or 20% compared to standard Micro-D. Designed to meet the performance requirements of MIL 83513, it integrates key features such as reversed contacts, integrated 90° back protection and interchangeable hardware.

Suited to both board-to-board (thanks to its secure wiping length) and board-to-wire (from gauge 24 to gauge 30) configurations, EMM will provide extreme modularity with any pin selection available from 04 to 60 signal contacts. Cable versions can be cabled at Nicomatic, or you can crimp them by yourself: it is up to you!



Can't find what you're looking for? Send us your specifications & let us help you find the best solution for you!

EMM self declaration of conformity
IILF02 - EMM
EMM PR with Amphenol
ICLF02 - EMM
EMM Catalog
Railway Self Declaration according to EN45545.
Usage instruction for EMM Range
no-img
Nicomatic and Amphenol Socapex conclude an agreement on the rectangular 1.27 mm pitch connector developed by Nicomatic

Nicomatic, the French company recognized for the design and manufacture of miniature, rugged connector systems, and Amphenol Socapex, the world-renowned manufacturer of rugged interconnection solutions have signed a dual-sourcing agreement, whereby Amphenol Socapex will sell Nicomatic’s modular, 1.27mm pitch rectangular EMM connector family under the brand MICRO HDAS. This will benefit customers in hirel industries who require a dual source for this innovative connector.

Instant 2D Drawing for Nicomatic’s New EMM 1.27 mm Micro-Connector

Visitors to Nicomatic’s website now have access to instant 2D drawings for our new miniaturized & rugged 1.27 mm EMM Connector. In addition, each 2D drawing also displays product specifications on the second page.

MyNicomatic users can also request 3D Drawings, Pricing, Samples, or ask a Technical Question. Nicomatic part specific 3D drawings are available in just 48 hours in a variety of convenient formats: IGES (.igs), STEP (.stp), PARASOLID (.xt), and/or 3D PDF (.pdf).
